CIVITAS/CORE Platform Architecture
The following figure depicts the overall architecture of the platform. The blue boxes represent the platform stacks. The lines represent the communication paths between the stacks. Each stack is deployed into a separate Kubernetes namespace, at least in the default configuration.
